Model Specifications

Model Cutting Width Cutting Height Cutting Height w/Optional High-Stubble Shoes Cutterbar Tilt Angle Type Cutterbar Number of Discs /Knives per Disc
DC133 (roll) 156 in. (4.0 m) 20 - 69 mm (0.79 - 2.7 in.) 79 - 140 mm (3.1 - 5.5 in.) 2 - 10 Modular 8/2
DC133 (flail) 156 in. (4.0 m) 20 - 69 mm (0.79 - 2.7 in.) 79 - 140 mm (3.1 - 5.5 in.) 2 - 10 Modular 8/2
DC163 (roll) 192 in. (4.9 m) 20 - 69 mm (0.79 - 2.7 in.) 79 - 140 mm (3.1 - 5.5 in.) 2 - 10 Modular 10/2
DC163 (flail) 192 in. (4.9 m) 20 - 69 mm (0.79 - 2.7 in.) 79 - 140 mm (3.1 - 5.5 in.) 2 - 10 Modular 10/2
