Soak in the quiet hum of success with Gravely’s Pro-Turn EV 48″. This unit features four swappable batteries to deliver the all-day, reliable high-performance power you need in a commercial mower. No pulleys, belts, engine oil changes, or driving vibrations will hold you back.
Our proprietary spindles have a blade slip feature that prevents damage in the event of an impact. They also have a bottom bearing for easy serviceability and routine maintenance which avoids the need to replace the entire spindle. Its high-tech display screen keeps the operator in the know with information on the battery charge, blade engagement, and alerts if an issue needs to be addressed.
For more information on how we collect, hold, use and disclose personal information, please see our privacy policy.
Click on the images below to enlarge.
| Specifications | |
|---|---|
| Model | AGU997005 |
| Engine Manufacturer | 4 x 16 KWH Fusion Core Lithium Ion |
| Horsepower / Displacement | 5 KW Wheel Drive Motor / 3.5 kw Per Spindle Motor |
| Drive System | Proprietary Electric Transaxles |
| Fuel Capacity | N/A |
| Ground Speed | 12.8 KM/H Forwards / 6.4 KM/H Backwards (Low Speed), 17.7 KM/H Forwards, 8.8 KM/H Backwards (High Speed) |
| Deck Size | 48" |
| Deck Material | 7 GA. |
| Deck Construction | Fabricated X-Factor 3 Deck |
| Number Of Spindles | 3 |
| Blade Tip Speed (FPM) | 18,000 FPM |
| Spindle Housing Material | Cast Aluminum |
| Spindle Bearings | Serviceable Bottom Bearing |
| Deck Engagement | Electric DC Brushless Motors |
| Deck Lift System | N/A |
| Cutting Width | 48 Inch |
| Cutting Positions / Height | 15 Cutting Positions (38.1 MM – 127 MM) |
| Wheels Front | 13 x 6.5 – 6 Smooth |
| Wheels Rear | 22 x 10 – 12 Turf |
| Seat | High Back Comfort W/ Suspension |
| Foldable ROPS | Standard |
| Weight | 572 KG |
| Length | 2108.2 MM |
| Width | 1270 MM With Chute Up, 1574.8 MM With Chute Down |
| Height | 1828.2 MM With ROPS Up, 1244.6 MM With ROPS Down |
| Warranty | 5 Year / 1500 Hour Commercial / 3 Year Battery Warranty |
