The ZT X 52″ is designed with a 4.5-inch deep fabricated deck with optimised airflow to produce the best quality cut and discharge performance. This residential mower is no match for your lawn and brings commercial-grade precision and legendary Gravely performance to any job you throw at it.
This unit also has a fully welded tubular frame with a professional grade backbone and a simple intuitive cutting selection solution, allowing you to press the pedal to raise the deck and turn the dial. The ZT X is built for homeowners who take their lawn care seriously.
For more information on how we collect, hold, use and disclose personal information, please see our privacy policy.
Click on the images below to enlarge.
| Specifications | |
|---|---|
| Model | AGU915257 |
| Engine Manufacturer | Kawasaki FR691V |
| Horsepower / Displacement | 23 HP / 726 CC |
| Drive System | Hydro-Gear ZT2200 Transaxles |
| Fuel Capacity | 10.5 L |
| Ground Speed | 11.2 KM/H Forwards, 4.8 KM/H Backwards |
| Deck Size | 52" |
| Deck Material | 11 GA. |
| Deck Construction | Fabricated |
| Number Of Spindles | 3 |
| Blade Tip Speed (FPM) | 18,000 FPM |
| Spindle Housing Material | Steel |
| Spindle Bearings | Sealed Bearings |
| Deck Engagement | Electric Warner |
| Deck Lift System | Foot Operated. Dial Selection |
| Cutting Width | 52 Inch |
| Cutting Positions / Height | 13 Cutting Positions / 38.1 MM – 114 MM |
| Wheels Front | 11 X 6 – 5 Smooth Pneumatic |
| Wheels Rear | 20 x 10 – 8 Turf |
| Seat | 18 Inch Plush High Back W/ Padded Arm Rests |
| Foldable ROPS | N/A |
| Weight | 291.2 KG |
| Length | 1968.5 MM |
| Width | 1384.3 MM With Chute Up, 1530 MM With Chute Down |
| Height | 1038.8 MM |
| Warranty | 3 Year / 300 Hour |
