Gravely’s ZT XL 60″ unit brings professional-grade quality to a residential machine with heavy-duty features that are designed to impress. Providing increased torque, a smoother ride, and a longer lifespan with the Hydro-Gear ZT02800 transaxles that allow you to tackle any big jobs thrown your way.
Plus, the 4.5 inch deep 11-gauge fabricated deck features an optimised airflow design to produce best in class quality and discharge performance. Coupled with a Kawasaki V-Twin Engine and a 10.5 litre fuel tank, you’ll be out mowing all day long without needing to stop!
For more information on how we collect, hold, use and disclose personal information, please see our privacy policy.
Click on the images below to enlarge.
| Specifications | |
|---|---|
| Model | AGU915264 |
| Engine Manufacturer | Kawasaki FR730V |
| Horsepower / Displacement | 24 HP / 726 CC |
| Drive System | Hydro-Gear ZT-2800 Transaxles |
| Fuel Capacity | 10.5 L |
| Ground Speed | 12 KM/H Forwards, 4.8 KM/H Backwards |
| Deck Size | 60" |
| Deck Material | 11 GA. |
| Deck Construction | Fabricated |
| Number Of Spindles | 3 |
| Blade Tip Speed (FPM) | 18,000 FPM |
| Spindle Housing Material | Steel |
| Spindle Bearings | Sealed Bearings |
| Deck Engagement | Electric Warner |
| Deck Lift System | Foot Operated. Dial Selection |
| Cutting Width | 60 Inch |
| Cutting Positions / Height | 13 Cutting Positions / 38.1 MM – 114 MM |
| Wheels Front | 11 X 6 – 5 Smooth Pneumatic |
| Wheels Rear | 20 x 12 – 10 Turf |
| Seat | 18 Inch Plush High Back W/ Padded Arm Rests. Seat Slider & Seat Isolation Standard |
| Foldable ROPS | N/A |
| Weight | 316.1 KG |
| Length | 1968.5 MM |
| Width | 1636 MM With Chute Up, 1872 MM With Chute Down |
| Height | 1066.8 MM |
| Warranty | 4 Year / 400 Hour |
